New TC6513 Hammer Head Tower Crane with Jib 65m Tipe Load 1.3t
Max.load 8t
Quick Details
1.TC6513 Topkit Tower Crane
2. Type: fixed and external climbing
3. Jib length: 65m
4. Tip load: 1.3t
5. Max.laod: 8t
6.Freestanding height:50m
Specification
| Model | TC6513 Tower Crane |
| Working Radius (m) | 65 |
| Max. Load Capacity (T) | 8 |
| Tip Load (T) | 1.3 |
| Free standing height (m) | 45 |
| Max. Height with anchorages (m) | 150 |
| Mast Section dimension (m) | 1.835*1.835*2.5m |
Hoisting Mechanism
| Speed (m/min) | 0-80 0-40 |
| Motor power (kw) | 30/30 |
Slewing Mechanism
| Speed (r/min) | 0.6 |
| Motor power (kw) | 2*3.7 |
Trolleying Mechanism
| Speed (m/min) | 40 |
| Motor power (kw) | 3.3/2.2 |
Jacking-up System
| Speed (m/min) | 0.4 |
| Motor power (kw) | 5.5 |
| Total Power (kw) | 46.2 |
| Power Supply | 380V/50Hz, 220V/60Hz or others |
Introduction:
1. TC6513 Topkit Tower Cranes can handle high load capacities and
have an unmistakable silhouette.
2. The various size classes prove their worth for medium and large
construction projects, for example for industrial and plant
construction.
3. Customers around the world rely on our top-slewing cranes for
major building projects. The intelligent high-performance drive
units ensure high handling capacities and thus enhance efficiency.
4. The modular design means that top-slewing cranes can adjust to
any specific requirement. We offer customers rapid erection and
bespoke solutions.
5. Tower cranes are also suitable for use on very high buildings.
Our customers benefit from enormous hoisting heights and hoist
speeds.
Our Service
------Quality Assurance
Good quality is assured by advanced manufacturing technology. And
all products will be checked by our quality-control manager.
------Excellent Package
We provide standard, strong, protective package for our products to
prevent it from outer damage.
------Warranty Assurance
For our tower crane, we provide 1 year warranty period and quick
replace service.
------The Fastest Reply
Detailed information,specific model and price of products will be
provided quickly after receiving inquiry.
Competitive Advantage
1. Focusing on tower crane exporting for 15 years;
2. Manufacturer's representative;
3. Preferential ex-factory price, excellent product quality and
good after-sales service are our pursuit;
4. Our tower cranes had exported to more than 20 countries, such as
Vietnam, Philippines, Indonesia, India, Sri Lanka, Cambodia,
Russia, Kazakhstan, Brazil, Cyprus, Belgium, Madagascar and Algeria
etc.
Pictures
